| Ratio
|
200/5 |
| Rated Burden
(VA)
|
5 |
| Class of Accuracy
|
0.5 |
| Rated Frequency
(Hz)
|
50/60 |
| Maximum Operating Voltage
(V)
|
720 |
| Insulating Class
|
E |
| Rated Insulation Test Voltage
|
3/4 kV AC for 1 Minute |
| Instrument Security Factor FS
|
FS 5 or 10 |
| Rated Thermal Short Time Current For BPL
(mm²)
|
Ith = 60*Ipr |
| Rated Thermal Continuous Current
|
Icth = 1.2*Ipr |
| Rated Thermal Surge Current
|
Idyn = 2.5*Ith |
| Permissible Humidity Operation
|
<95% RH |
| Ambient Temperature Operation
|
-20°C ... +50°C |
| Ambient Temperature Storage
|
-40°C ... +70°C |
| Max Altitude
|
=1000 m |
| ROHS
|
NO |
| Din Rail Mounting Option
|
- |
| CE
|
Yes |
| Mounting Plate
|
Available on request |
| Terminal Cover
|
Without Sealing |
